V-Stay Rods
High-Strength V-Stay Rods for Axle Stability & Suspension Alignment
Our V-Stay Rods are engineered to control axle movement, maintain suspension geometry, and absorb dynamic forces in heavy commercial vehicles. Designed for high tensile strength and fatigue resistance, they ensure vehicle stability, reduced vibration, and extended suspension life under demanding road and load conditions.
Material
EN8 / EN19 / Alloy Steel
Finish
Powder Coated / Zinc Plated / Phosphate
Hardness
22–32 HRC
Tolerance
Manufactured as per ISO / OEM drawings
Applications
Trucks
Trailers
Buses
Tractors
Quality Certified
Custom Available
Full Documentation
Technical Specifications
Material
EN8 / EN19 / Alloy Steel
Finish
Powder Coated / Zinc / Phosphate
Hardness
22–32 HRC
Design
V-Type / Custom Geometry
Additional Details
Bush Type
Rubber / Polyurethane / Metal
Rod Construction
Welded / Machined
Length Range
As per suspension design
End Fittings
Eye / Pin / Custom
Available Sizes – V-Stay Rods
Standard V-Stay Rod sizes available. Custom lengths and bush options on request.
| Part Number | Rod Diameter | Center Length | Approx. Weight |
|---|---|---|---|
| VSR-32 | Ø32 mm | 480–520 mm | 6.0–7.5 kg |
| VSR-36 | Ø36 mm | 500–560 mm | 7.5–9.0 kg |
| VSR-40 | Ø40 mm | 520–600 mm | 9.0–11.5 kg |
| VSR-45 | Ø45 mm | 560–650 mm | 11.5–14.5 kg |
| VSR-50 | Ø50 mm | 600–720 mm | 14.0–18.0 kg |
Need a different size or bush type?
Request a custom quote
Case carburized & hardened
Precision ground to mirror finish
Straightness guaranteed
Available with bronze bushes
Complete king pin kits available
PPAP documentation on request
Primary Applications
Vehicle Types
Need a Quote for V-Stay Rods?
Send us your requirements and receive a detailed quotation within 24 hours
